Blaci de baza GIGABYTE MB GIGABYTE A520M DS3H V2 AM4
GIGABYTEPlaca de baza GIGABYTE A520M DS3H V2 AM4, 4x DDR4, 1x DP 1x HDMI, 1 PCIE x16 1x PCIE x1, 1x M.2, 4x SATA 6gb/s
Placa de baza GIGABYTE A520M DS3H V2 AM4, 4x DDR4, 1x DP 1x HDMI, 1 PCIE x16 1x PCIE x1, 1x M.2, 4x SATA 6gb/s
- Conectivitate
- Da
- Producator procesor
- AMD
- Brand
- GIGABYTE
- Memorie RAM (GB)
- 128
- Tip memorie RAM
- DDR4
DDR4-SDRAM - USB 3.2
- 0
4 - HDMI
- 1
- Battery technology
- Lithium-Manganese Dioxide (LiMnO2)
- Number of battery cells
- 1
- USB 2.0 ports quantity
- 2
- Depth
- 24.4 mm
- Width
- 244 mm
- Height
- 35 mm
- HDMI version
- 2.1
- Audio Chip
- Realtek ALC887
- Memory channels
- Dual-channel
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 0
- Bundled software
- Norton® Internet Security (OEM version), Realtek® 8118 Gaming LAN Bandwidth Control Utility
- Battery weight
- 3 g
- Country of origin
- China
- Wi-FI
- Nu
- Package height
- 54 mm
- Package width
- 265 mm
- Package depth
- 265 mm
- Package weight
- 810 g
- USB connector type
- USB Type-A
- Headphone outputs
- 1
- Lithium weight per battery
- 0.07 g
- Battery type
- CR2032
- Clear CMOS button
- Da
- BIOS memory size
- 128 Mbit
- ACPI version
- 5.0
- Desktop Management Interface (DMI) version
- 2.7
- System Management BIOS (SMBIOS) version
- 2.7
- BIOS type
- UEFI AMI
- Clear CMOS jumper
- Da
- Audio output channels
- 7.1 channels
- Cooling type
- Active
- Component for
- PC
- PC health monitoring
- CPU, LED, Power supply, Temperature, Voltage
- Windows operating systems supported
- Windows 10 x64
- Power source type
- ATX
- Maximum resolution
- 5120 x 2880 pixels
- USB 2.0 connectors
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 1
- Number of SATA III connectors
- 4
- Front panel audio connector
- Da
- ATX Power connector (24-pin)
- Da
- CPU fan connector
- Da
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 0
- Front panel connector
- Da
- TPM connector
- Da
- 12V power connector
- Da
- ECC сompatibility
- ECC & Non-ECC
- Memory slots type
- DIMM
- Unbuffered memory
- Da
- Ethernet interface type
- Gigabit Ethernet
- Compatible processor series
- AMD Ryzen 3000 Series, AMD Ryzen Threadripper 3000 Series, AMD Ryzen Threadripper PRO 3000 WX-Series
- Supported processor sockets
- Socket AM4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 0
- DisplayPort version
- 2.0
- Digital audio optical out
- 1
- DisplayPorts quantity
- 1
- VGA (D-Sub) ports quantity
- 0
- DVI-D ports quantity
- 1
- RAID support
- Da
- Number of HDDs supported
- 4
- Number of storage drives supported
- 5
- Supported storage drive types
- HDD & SSD
- Onboard-CPU
- Nu
- PCI
- 0
- Serial-or-Paralel
- No/No
- Cables included
- SATA
- Drivers included
- Da
- Maximum internal memory supported by processor
- 128 GB
- Socket procesor
- Socket AM4
- Number of displays supported
- 3
- HDCP
- Da
- Microphone in
- Da
- Supported memory clock speeds
- 2133,2400,2667,2933,3200,3333,3600,4000,4400,4733 MHz
- Numar sloturi memorie
- 4
- Serial port headers
- 1
- PS/2 ports quantity
- 1
- PCI Express x1 (Gen 3.x) slots
- 2
- PCI Express x16 (Gen 3.x) slots
- 1
- Number of SATA II connectors
- 0
- Total number of SATA connectors
- 4
- Number of Parallel ATA connectors
- 0
- Maximum number of SMP processors
- 1
- eSATA ports quantity
- 0
- Firewire (IEEE 1394) ports
- 0
- Discrete graphics support
- Da
- Power fan connector
- Da
- Supported memory module capacities
- 1GB, 2GB, 4GB, 8GB, 16GB, 32GB
- Number of EATX power connectors
- 1
- Numar sloturi M.2
- 1
- Format placa de baza
- micro ATX
- Familie chipset
- AMD
- Niveluri RAID
- 0, 1, 10
- Interfete stocare
- M.2, SATA III
4719331854690
