Blaci de baza ASROCK MB Asrock B450 Pro4 R2.0 AM4
ASROCKPlaca de baza Asrock B450 Pro4 R2.0 AM4 Supports AMD AM4 Socket Ryzen™ 2000, 3000, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors Supports DDR4 3200+ (OC) 2 PCIe 3.0 x16, 4 PCIe 2.0 x1 AMD Quad CrossFireX™ Graphics Output: HDMI, Display Port, D-Sub 7.1 CH HD Audio (Realtek ALC892/897 Audio Codec) 6 SATA3, 1 Ultra M.2 (PCIe Gen3 x4), 1 M.2 (PCIe Gen3 x2 & SATA3) 2 USB 3.2 Gen2 (Rear Type A+C) 6 USB 3.2 Gen1 (2 Front, 4 Rear) Realtek Gigabit LAN https://www.asrock.com/mb/AMD/B450%20Pro4%20R2.0/index.asp
Placa de baza Asrock B450 Pro4 R2.0 AM4 Supports AMD AM4 Socket Ryzen™ 2000, 3000, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors Supports DDR4 3200+ (OC) 2 PCIe 3.0 x16, 4 PCIe 2.0 x1 AMD Quad CrossFireX™ Graphics Output: HDMI, Display Port, D-Sub 7.1 CH HD Audio (Realtek ALC892/897 Audio Codec) 6 SATA3, 1 Ultra M.2 (PCIe Gen3 x4), 1 M.2 (PCIe Gen3 x2 & SATA3) 2 USB 3.2 Gen2 (Rear Type A+C) 6 USB 3.2 Gen1 (2 Front, 4 Rear) Realtek Gigabit LAN https://www.asrock.com/mb/AMD/B450%20Pro4%20R2.0/index.asp
- Conectivitate
- Da
- Producator procesor
- AMD
- Chipset
- AMD B450
- Brand
- ASROCK
- Rezoluție
- HD
- Memorie RAM (GB)
- 128
- Tip memorie RAM
- DDR4
DDR4-SDRAM - USB 3.2
- 0
4 - HDMI
- 1
- USB 2.0 ports quantity
- 2
- Depth
- 224 mm
- Width
- 30.5 mm
- HDMI version
- 1.4
- Audio Chip
- Realtek ALC892 / Realtek ALC897
- Memory channels
- Dual-channel
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- Bundled software
- ASRock A-Tuning ASRock Polychrome SYNC ASRock XFast LAN
- Harmonized System (HS) code
- 84733020
- Wi-FI
- Nu
- BIOS memory size
- 128 Mbit
- ACPI version
- 5.1
- System Management BIOS (SMBIOS) version
- 2.3
- BIOS type
- UEFI AMI
- Audio output channels
- 7.1 channels
- Component for
- PC
- PC health monitoring
- Fan, Temperature, Voltage
- Windows operating systems supported
- Windows 10 x64
- Maximum resolution
- 4096 x 2160 pixels
- Parallel processing technology support
- CrossFireX, Quad-GPU CrossFireX
- DirectX version
- 12.0
- USB 2.0 connectors
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 1
- Number of SATA III connectors
- 6
- Front panel audio connector
- Da
- ATX Power connector (24-pin)
- Da
- CPU fan connector
- Da
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 0
- Number of chassis fan connectors
- 3
- TPM connector
- Da
- RGB LED pin header
- Da
- 12V power connector
- Da
- ECC сompatibility
- ECC & Non-ECC
- Memory slots type
- DIMM
- Unbuffered memory
- Da
- Ethernet interface type
- Gigabit Ethernet
- LAN controller
- Realtek RTL8111H
- Compatible processor series
- AMD Athlon, AMD Ryzen 3000 Series, AMD Ryzen 5000 Series
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 1
- DisplayPort version
- 1.2
- DisplayPorts quantity
- 1
- VGA (D-Sub) ports quantity
- 1
- DVI-D ports quantity
- 0
- Ethernet LAN (RJ-45) ports
- 1
- RAID support
- Da
- MB-Socket
- AM4
- MB-Format
- ATX
- PCI-Ex1
- 1
- PCI-Ex16
- 2
- RAM-Slots
- 4
- USB3
- 4-8
- PCI
- 0
- Serial-or-Paralel
- No/No
- Cables included
- SATA
- Drivers included
- Da
- Certification
- FCC, CE, ErP/EuP
- Socket procesor
- Socket AM4
- Number of displays supported
- 3
- HDCP
- Da
- Supported memory clock speeds
- 2133,2400,2667,2933,3200 MHz
- Numar sloturi memorie
- 4
- PS/2 ports quantity
- 1
- PCI Express x16 (Gen 3.x) slots
- 2
- Wake-on-LAN ready
- Da
- Maximum number of SMP processors
- 1
- Number of COM connectors
- 1
- PCI Express x1 (Gen 2.x) slots
- 4
- CPU încorporat
- Nu
- Numar sloturi M.2
- 2
- Format placa de baza
- ATX
- Familie chipset
- AMD
- Niveluri RAID
- 0, 1, 10
- Interfete stocare
- M.2, SATA III
